Integration testing foundation for .NET

Test the whole journey. Trace every layer.

Compose your application, data and clients once for the suite. Every test gets its own context, owned cleanup and a trace that explains what happened, across APIs, databases, browsers and messages.

Get startedOpen a sample trace

.NET 8, 9 & 10 · NUnit, xUnit, MSTest & TUnit · MIT

[ProtoTest]
[SignedInAs]
public async Task RestWritesAreVisibleThroughGraphQL()
{
    using var created = await Proto.Context.Rest()
        .Body(new CreateProjectRequest("atlas"))
        .PostAsync("/api/v1/projects");
    created.Should.HaveHttpStatus(HttpStatusCode.Created);
    using var projects = await Proto.Context.GraphQL()
        .Query("projects", new { first = 10 })
        .ExpectAsync(new
        {
            totalCount = 1,
            nodes = new[] { new { name = "atlas", status = ProjectStatuses.Active } }
        });
    projects.Should.HaveNoErrors();
}
PlatformJourney.cs. The class selects the application and provisions a Northstar member.

In 70 seconds

One test, from the failure to the proof.​

Follow one real test from the OpenCSMS demo. A pull request breaks the station screen, the comment names the cause, the trace shows the page as it failed, and one command proves the fix.

The player loads from YouTube when you press play. Watch on YouTube ↗

Less plumbing

Setup moves out of the test.​

The same scenario against the same application, written as a plain fixture and with ProtoTest. The scenario lines stay; the plumbing around them is composed once for the suite or declared on the test that needs it.

Compare both files, line by line →
Without ProtoTest35
With ProtoTest13
lines of plumbing in each fixture, for the same scenario
Run the application
A factory per fixtureThe suite host
A tenant of its own
SetUp and a helperAn attribute
Authenticate each call
Shared default headersPer test, from its context
Clean up after a failure
TearDown, if SetUp got farOwned, reversed and traced

Evidence

A failure explains itself.​

Every call, check, wait and cleanup lands in a .prototrace archive next to the report. Open it and the failing check is one step away, with the values that differed and the source line that asserted them.

The trace also shows time nothing was recorded, so a real wait is visible instead of guessed.

Open this run in the viewer ↗How the trace works →
ProtoTrace viewer · failing check

Test execution / REST · GET /api/v1/organization

CheckAssert response shape

Failed2.2 ms+1.15 s into the test

Validated document✓ matched × expected, then actual
× "status": "past_due" → "active"
The response it judged
{ "status": "active", "planId": "growth", "seatCount": 1, ... }
FailureDrills.cs:36Northstar.ProtoTest.FailureDrills.ARealWaitDoesNotCloseTheDueWindow
33await Task.Delay(TimeSpan.FromSeconds(1));34 35using var organization = await Proto.Context.Rest().GetAsync("/api/v1/organization");36organization37    .Should.HaveHttpStatus(HttpStatusCode.OK)38    .Should.MatchShape(new { status = SubscriptionStatuses.PastDue });39}

Evidence

File597539000012-rest-01-expected-shapeapplication/json, 21 B
Exception JsonShapeMismatchException

Shape mismatch failed with 1 error(s): [$.status]: Values did not match. (Expected: "past_due", Actual: "active")

Attributes 12

The shape check's 12 recorded attributes; open the run in the viewer to read them.

Test 12 from prototest-demo.prototrace, as the inspector shows it.

For coding agents

Your agent reads the evidence, not the logs.​

A local MCP server hands a coding agent the failed check, the call it judged and the source line as one small document. The agent spends its context on the fix instead of on finding out what happened.

The server is read-only and nothing leaves the machine: no account, no telemetry, no upload. The same diagnosis renders in a terminal and in the pull request comment.

Connect your agent →The evidence loop in CI →
Coding agent · one failing test
  1. list_runs1 run · 1 test failed
  2. get_failureTheAddressWasHardcodedForOneMachine · connection refused · Program.cs:65
  3. get_diagnosisthe call it judged, its ancestors, the source snippet, the state changes
  4. editthe file and line the diagnosis named
  5. prototest verifythe pull request verdict: coverage, contract and run gates
The turns from the coding agents example. Docs for agents: llms.txt.

One model

Different boundaries. The same test.​

Choose the integrations your scenario crosses. Each joins the same host, context, cleanup and trace, so one test can write through an API and read back from the database or the browser.

Every integration ProtoTest covers arrives as its own line and joins the same run.

Exercise your APIs

REST, GraphQL and gRPC clients with shared authentication, shape checks and contract coverage.

Supported

Arrange data and inspect the store

Reusable test data, test-scoped SQL connections and EF Core contexts, with optional transaction rollback.

Supported

Follow a journey in the browser

Page objects and flows through Playwright or Selenium, with screenshots and page coverage.

Supported

Publish and await messages

In-memory messaging or RabbitMQ. Add the MassTransit bridge when you need its test harness.

Supported · MassTransit preview

Compose the environment

ASP.NET Core, background workers and run-owned containers. Aspire and WireMock are available in preview.

Supported · preview extensions

Reach devices and documents

Typed device clients over WebSocket, MQTT, TCP or a serial port, and assertions on generated Excel workbooks.

Preview

Every integration → · Recipes that combine them · Build one for your own domain

How it fits

Your runner runs the tests. ProtoTest holds what is around them.​

  1. 01

    Compose the host

    Applications, clients and infrastructure, registered once for the suite.

    Host composition →
  2. 02

    Arrange the context

    Attributes and builders prepare the identity, data and clients one test needs.

    Execution context →
  3. 03

    Own the cleanup

    Whatever a test provisions is released in reverse order, also when it fails.

    Lifecycle and cleanup →
  4. 04

    Keep the evidence

    Calls, checks and cleanup land in the test’s trace, report and coverage.

    Trace and reports →

Keep your runner and your assertions. Add a setup class and the integrations you need, then move one scenario at a time. Compare the setup · Choose your runner · Adoption and exit costs

< 1 msof a 36 ms test in a real suite with a database and a broker is ProtoTest. Where the rest goes →

Try it

Your first suite, ready to run.​

The template creates a small API and four integration tests. The .NET 10 SDK is enough. The default starter runs without containers or a browser.

After the green run, the trace and HTML report are under Shop.Tests/bin/Debug/net10.0/TestResults/.

Installation and options · Learn with the Northstar sample

Create and run Shop
Runner
dotnet new install ProtoTest.Templates
dotnet new prototest -n Shop
cd Shop
dotnet test

Why ProtoTest exists​

Once an integration suite grows, most of the work shifts to setup, infrastructure and failures that only happen sometimes. ProtoTest gives every integration the same context, lifecycle and trace, so that work is solved once. What is specific to your application stays in your test project. Project and support

Latest release: 1.1.9 · 10 oct 2026Release notes →
